W-Band Bias Tuned Gunn Oscillator

94 GHz, ±500 MHz Tuning Bandwidth, +17 dBm Output Power, WR-10 Waveguide
SKU:SOB-94301317-10-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SOB-94301317-10-S1 is a W-band, bias tuned Gunn oscillator that utilizes a high performance GaAs Gunn diode and proprietary cavity design to deliver +17 dBm typical power, useful for phase-locking and electrical tuning applications. The oscillator features a bias frequency tuning range of 93.5 to 94.5 GHz and delivers low AM/FM noise and harmonic emissions. Compared to its counterparts, such as multiplier based sources, the Gunn oscillator is a lower cost and cleaner source. The Gunn oscillator's frequency can also be tuned mechanically. The Gunn oscillator is equipped with a self-locking set screw for frequency trimming. The performance of the oscillator can be further enhanced by adding an optional isolator, Gunn oscillator modulator/regulator and temperature heater.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 2$4,000.00
3 - 4$3,800.00
5 - 9$3,610.00

Bulk Pricing

Login to View Pricing

Technical Details

Center Frequency94 GHz
Output Power+17 dBm
Mechanical Tuning Range±100 MHz
Bias Tuning Range (+3.5 to +4.5 VDC)±500 MHz
Bias+4.0 VDC/750 mA
RF PortWR-10 Waveguide
Mechanical TuningSelf-Locking Set Screw
