W-Band Receiver

90 to 96 GHz, 6 dB Noise Figure, 30 dB RF to IF Conversion Gain
SKU:SSR-9330636030-10-M1
Availability:4 to 6 Weeks ARO
SSR-9330636030-10-M1 is a W-Band receiver. The receiver has a typical conversion gain of 30 dB with a typical RF input power of -60 dBm in the frequency range of 90 to 96 GHz and a IF output frequency range of 2 to 6 GHz. The required LO power and frequency range are 0 dBm and 11.25 GHz. The LO and IF port are both equipped with female SMA connectors and the RF port is a WR-10 waveguide with a UG-387/U-M flange.
ECCN: EAR99
Login to View Pricing

Technical Details

RF Input Minimum Frequency90 GHz
RF Input Maximum Frequency96 GHz
Conversion Gain30 dB
LO Frequency11.625 GHz
LO Input Power5 dBm
Bias Voltage6 VDC
RF PortWR-10 Waveguide
