F-Band DPDT Motorized Latching Switch with TTL Driver, Manual Override, WR-08, E-Plane

SWJ-08-LM1 is a WR-08 motorized double pole, double throw (DPDT) transfer switch with a TTL driver that operates from 90 to 140 GHz. It is an E-plane, bidirectional, latching-type switch with a manual override knob. The typical insertion loss is 1.0 dB and the typical isolation is 50 dB. The RF ports are WR-08 waveguides with UG-387/U-M anti-cocking flanges. The bias and control signal is supplied by a 9 pin Micro-D type connector.
