F-Band Negative Amplitude Detector

90 to 140 GHz, 300 mV/mW Sensitivity, WR-08 Waveguide
SKU:SFD-903144-08SF-N1
Availability:1 Week ARO
SFD-903144-08SF-N1 is an F Band amplitude detector that can be used for full or narrow band applications. The detector is zero biased and intended for small signal detection purposes. With a distinct circuitry design and careful diode selection, the detector exhibits high sensitivity and extremely flat output characteristics. The detector is designed to have a 10 MHz video bandwidth and a 1 milliohm video output impedance. The minimum detectable signal level is approximately -50 dBm.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 4$1,850.00
5 - 9$1,665.00
10 +$1,498.50

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency90 GHz
Maximum Frequency140 GHz
Sensitivity300 mV/mW
Sensitivity Flatness±2.0 dB
RF Input Power-20 dBm
Video Bandwidth10 MHz
Output Voltage PolarityNegative
RF PortWR-08 Waveguide
DC PortSMA (F)
