4-Way In-line Power Divider

SWP-90310404-10-E1 is a W band, 4-way power divider with a typical insertion loss of 1.0 dB across the frequency range of 90 to 105 GHz. The divider offers 20 dB isolation and well balanced ports, which can be used for in-phase power dividing or combining. This power divider comes as an in-line configuration with WR-10 waveguides and UG-387/U-M anti-cocking flanges at the input and all outputs.
