Dielectric Resonator Oscillator

9 GHz, ±20 MHz Tuning Range, +13 dBm Output Power, SMA (F)
SKU:SOD-09302113-SF-C2
Availability:Contact Us for Quote
SOD-09302113-SF-C2 is a mechanically tuned, dielectric resonator oscillator with a center frequency of 9 GHz and a mechanical tuning range of ±20 MHz. The oscillator delivers a nominal output power of +13 dBm with a low phase noise and low harmonic emissions.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Center Frequency9.0 GHz
Output Power+13 dBm
Mechanical Tuning Range±20 MHz
Phase Noise-80 dBc/Hz @ 100 KHz Offset
Spurious-75 dBc
Harmonics-25 dBc
Bias+12 VDC/40 mA
RF PortSMA (F)
