X8 Active Frequency Multiplier

SFA-883104826-10SF-E1 is an active X8 frequency multiplier. The multiplier has an input frequency of 11 to 12.5 GHz with a typical input power of +5 dBm and an output frequency of 88 to 100 GHz with a typical output power of +26 dBm. The multiplier also has a typical harmonic suppression of -15 dBc. The DC power requirement for the multiplier is +8 VDC/1800 mA. The input port configuration is a female SMA connector and the output is a WR-10 waveguide with a UG-387/U-M anti-cocking flange. Other port configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
