2-Way Coaxial Power Splitter

8 to 12.4 GHz, SMA (F)
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SCS-0831230520-SFSF-22 is a coaxial 2-way power splitter with a typical insertion loss of 0.5 dB at each output port and a typical isolation of 20 dB across the frequency range of 8 to 12.4 GHz. The power splitter has a nominal power handling of 30 W (CW) and a typical amplitude unbalance of ±0.3 dB. The return loss for all ports is 15 dB typical. The RF connectors of the power splitter are female SMA connectors.
Login to view pricing

Bulk Pricing

Quantity Price
1 - 24 $240.00
25 - 49 $216.00
50 - 99 $194.40

Bulk Availability


Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency8 GHz
Maximum Frequency12.4 GHz
Insertion Loss0.5 dB
Port Isolation20 dB
Return Loss15 dB
Impedance50 Ohms
RF ConnectorsSMA (F)
