X-Band Microstrip Patch Antenna

8 dBi Gain, 8.4 to 8.5 GHz, SMA (F)
Availability:IN STOCKPlease contact us if you need more units than what is available online.
This model may be purchased with optional antenna testing services.
A gain measurement test is offered under service number FTA-0400GAIN-PA.
A 2D pattern measurement test is offered under service number FTA-0400PATT-PA.

CLICK HERE to read more about our antenna measurement capabilities.

SAM-8428520865-SF-L1 is a linear polarized, 8,450 MHz microstrip patch antenna. The antenna has a typical gain of 8 dBi and a beamwidth of 65 degrees vertically and horizontally. The antenna is constructed with a high performing, low loss soft microwave substrate to achieve the best performance in the class. The RF interface is a female SMA connector.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency8.4 GHz
Maximum Frequency8.5 GHz
Gain8 dBi
3 dB Beamwidth (Vertical, Horizontal)65°, 65°
Sidelobe Level-
Return Loss10 dB
Antenna PortSMA (F)
