X-Band Microstrip Patch Antenna

8 dBi Gain, 7.145 to 7.235 GHz, SMA (F)
SKU:SAM-7127220865-SF-L1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAM-7127220865-SF-L1 is a linear polarized, 7,190 MHz microstrip patch antenna. The antenna has a typical gain of 8 dBi and a beamwidth of 65 degrees vertically and horizontally. The antenna is constructed with a high performing, low loss soft microwave substrate to achieve the best performance in the class. The RF interface is a female SMA connector.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency7.145 GHz
Maximum Frequency7.235 GHz
Gain8 dBi
3 dB Beamwidth (Vertical, Horizontal)65°, 65°
Sidelobe Level-
Return Loss10 dB
PolarizationLinear
Antenna PortSMA (F)
