X-Band Spot-Focusing Lens Antenna

SAQ-103039-90-S1 is an X-band spot-focusing lens antenna that delivers a 10 dB spot size of 1.75" at a focal length of 3.94". The antenna employs a low loss lens to offer excellent aperture efficiency at 10.3 GHz. The spot-focusing lens antenna is equipped with a WR-90 waveguide and UG-39/U flange as its antenna port. It supports linear polarized waveforms. For the intended application, it is recommended that customers purchase spot-focusing antennas (SAQ Series) in a pair of two (Qty. 2).
