X6 Active Frequency Multiplier

78 to 98 GHz, +16 dBm Output Power, In-line WR-10 Waveguide, W-Band
SKU:SFA-783983616-10SF-E1
Availability:1 Week ARO
SFA-783983616-10SF-E1 is an active X6 frequency multiplier. The multiplier has an input frequency of 13.0 to 16.33 GHz with a typical input power of 0 to +5 dBm and an output frequency of 78 to 98 GHz with a typical output power of +16 dBm. The multiplier also has a typical harmonic suppression of -20 dBc. The DC power requirement for the multiplier is +8 VDC/750 mA. The input port configuration is a female SMA connector and the output is a WR-10 waveguide with a UG-387/U-M anti-cocking flange. Other port configurations are available under different model numbers.
ECCN: 3A001.b.4.e.3
Login to View Pricing

Bulk Pricing

QuantityPrice
1 $5,550.00
2 $5,272.50
3 - 4$5,008.88

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Output Frequency78 GHz
Maximum Output Frequency98 GHz
Output Power+16 dBm
Minimum Input Frequency13 GHz
Maximum Input Frequency16.33 GHz
Input Power+5 dBm
DC Bias+8 VDC/750 mA
Output PortWR-10 WG
Input PortSMA (F)
