E-Band Transmitter

76 to 81 GHz, +10 dBm LO Input Power, 12.5 GHz LO Frequency
SKU:SST-7930530810-12-S1
Availability:4 to 6 Weeks ARO
SST-7930530810-12-S1 is an E-Band integrated transmitter module. The transmitter has a typical conversion gain of 10 dB with a typical Psat of +11 dBm in the frequency range of 76 to 81 GHz and a I/Q IF frequency range of 1 to 6 GHz. The LO includes a X6 multiplier chain and requires +10 dBm at the frequency of 12.5 GHz. The LO and IF ports are both equipped with female SMA connectors and the RF port is a WR-12 waveguide with a UG-387/U flange.
ECCN: 3A001.b.4.e.2
To view pricing or check order status

Technical Details

RF Output Minimum Frequency76 GHz
RF Output Maximum Frequency81 GHz
P1dB8 dBm
Conversion Gain10 dB
LO Frequency12.5 GHz
LO Input Power10 dBm
Bias Voltage12 VDC
RF PortWR-12 Waveguide
