12" Flexible Waveguide Cable

SCG-10120-F1 is a 12” long WR-10 waveguide cable. The frequency range of the waveguide cable is 75 to 110 GHz. The cable allows for varied orientations of waveguide to waveguide connections. The cable has a typical insertion loss of 8.5 dB and a nominal return loss of 14 dB. The cable is flexible with minimum bend radius of 0.250”. Other lengths are offered under different model numbers.
