W-Band Positive Amplitude Detector

75 to 110 GHz, 800 mV/mW Sensitivity, WR-10 Waveguide
SKU:SFD-753114-103-10SF-P1
Availability:4 to 6 Weeks ARO
SFD-753114-103-10SF-P1 is a W Band amplitude detector that can be used for full or narrow band applications. The detector is zero biased and intended for small signal detection purposes. With a distinct circuitry design and careful diode selection, the detector exhibits high sensitivity and extremely flat output characteristics across the full waveguide operating bandwidth. The detector is designed to have a 10 GHz video bandwidth and a 1 MΩ video output impedance. The minimum detectable signal level is approximately -50 dBm.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 4 $1,800.00
5 - 9 $1,620.00
10 - 24 $1,458.00

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency75 GHz
Maximum Frequency110 GHz
Sensitivity800 mV/mW
Sensitivity Flatness±2.0 dB
RF Input Power-20 dBm
Video Bandwidth10 GHz
Output Voltage PolarityPositive
RF PortWR-10 Waveguide
DC PortSMA (F)
