W-Band Compact Faraday Isolator

STF-10-S1-C is a full band Faraday isolator that operates from 75 to 110 GHz. The Faraday isolator is constructed with a longitudinal, magnetized ferrite rod that causes a Faraday rotation of the incoming RF signal. The compact, robust package is ideal for system integration and testing applications. The Faraday isolator offers 28 dB typical isolation and 1.5 dB nominal insertion loss with good flatness. The input and output ports are WR-10 waveguides with UG-387/U-M flanges. A 90° twist configuration is available under model number STF-10-91-C.
