E-Band Diplexer

74 to 79 GHz Low Passband, 84 to 89 High Passband, 55 dB Rejection, WR-12 Waveguide
SKU:SWY-77387355-12-I2
Availability:Contact Us for Quote
SWY-77387355-12-I2 is an E band waveguide diplexer with a low passband of 74 to 79 GHz and a high passband of 84 to 89 GHz. The nominal insertion loss of the diplexer is 0.5 dB and the minimum isolation is 55 dB. Since both low and high passband frequencies can be changed by modifying the design, custom designs are available under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Low Passband Minimum Frequency74 GHz
Low Passband Maximum Frequency79 GHz
Insertion Loss0.5 dB
Rejection55 dB
High Passband Minimum Frequency84 GHz
High Passband Maximum Frequency89 GHz
Waveguide PortWR-12 Waveguide
