E-Band Linear to Circular Polarizer, Limited Run

71 to 83 GHz, 1.1 Axial Ratio, 0.125" Diameter Circular Waveguide
SKU:SAS-773-12512-F1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
This is a Limited Run model, so inventory may not be restocked. Customers who anticipate long-term requirements should consider SAS-753-14112-F1 as an alternative solution. Read more about Limited Run Products here.

SAS-773-12512-F1 is an E band, linear to circular polarizer that operates at 77 GHz with a ±6.0 GHz bandwidth. The polarizer offers a maximum insertion loss of 1.0 dB, a maximum axial ratio of 1.2, and a typical return loss of 20 dB. The polarizer is fixed and can be used for either right-handed or left-handed polarization based on the direction of the input signal. The polarizer is often combined with Eravant’s rectangular to circular waveguide transition (SWT-12125-SB) and WR-12 conical horn antenna (SAC-2309-125-S2) for various system applications
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Center Frequency77 GHz
Bandwidth±6 GHz
Insertion Loss0.5 dB
Axial Ratio1.1
Return Loss20 dB
Input/Output0.125" Diameter Circular Waveguide
