WR-12 Waveguide Bandpass Filter, Wellprice

This is a Wellprice model that may not be offered in the future. Customers who anticipate long-term requirements should consider SWF-80320340-12-B1 as an alternative solution. Read more about Wellprice Products here.

SWF-80320340-12-B1-WP is an E band waveguide bandpass filter with a passband frequency of 70 to 90 GHz and rejection frequencies from DC to 60 GHz and 93.3 to 130 GHz. The nominal insertion loss of the bandpass filter is 2.0 dB and the typical rejection is 40 dB. Since both low end and high end cut off frequencies can be selected by modifying the design, custom designs are available under different model numbers.
