Ka-Band Omnidirectional Antenna

7.5 dBi Gain, 26.5 to 40 GHz, WR-28 Waveguide
SKU:SAO-2734030810-28-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SAO-2734030810-28-S1 is a full band, WR-28 omnidirectional antenna that operates between 26.5 and 40 GHz. This vertically polarized antenna offers 360 degrees azimuth coverage with a 7.5 dBi typical gain and ±1 dB nominal gain flatness. The antenna features a half power beamwidth of 10 degrees in the vertical direction. The RF port of the antenna is equipped with WR-28 waveguide with UG-599/U flange. The version with 2.92 mm (F) interface is offered under model number, SAO-2734030345-KF-S1.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $1,600.00
5 - 9 $1,440.00
10 - 24 $1,296.00

Bulk Availability

QuantityAvailability
1 - 4In Stock

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency26.5 GHz
Maximum Frequency40 GHz
Gain7.5 dBi
Azimuth360°
3 dB Beamwidth, Vertical10°
Return Loss9 dB
InputWR-28 Waveguide
