WR-12 Waveguide Bandpass Filter, Wellprice

This is a Wellprice model that has been discounted for small cosmetic blemishes that do not affect longevity or performance. Customers who cannot accept any blemishes should consider the full-priced model SWF-69302340-12-B1 as an alternative solution. Read more about Wellprice Products here.

SWF-69302340-12-B1-WPC is an E band waveguide bandpass filter with a passband frequency of 69 to 71 GHz and rejection frequencies from DC to 65 GHz and 73 to 95 GHz. The nominal insertion loss of the bandpass filter is 1.5 dB and the typical rejection is 40 dB. Since both low end and high end cut off frequencies can be selected by modifying the design, custom designs are available under different model numbers.
