WR-10 Waveguide Lowpass Filter, Wellprice

This is a Wellprice model that has been discounted for small cosmetic blemishes that do not affect longevity or performance. Customers who cannot accept any blemishes should consider the full-priced model SWF-11412440-10-L1 as an alternative solution. Read more about Wellprice Products here.

SWF-11412450-10-L1-WPC is a W band waveguide lowpass filter with a passband frequency from 65 to 110 GHz and a rejection frequency 120 to 170 GHz. Due to the waveguide cut off nature, the low side of the filter has rejection range of DC to 56 GHz. The filter provides a nominal insertion loss of 3.5 dB across its passband and a typical rejection of 50 dB. Since the high end cutoff frequency can be changed by modifying the design, custom designs can be offered under different model numbers.
