E-Band Balanced Upconverter

60 to 90 GHz, DC to 30 GHz IF, +13 dBm LO Power, WR-12 Waveguide
SKU:SFU-12-N1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SFU-12-N1 is an E-Band balanced up-converter that utilizes high performance GaAs Schottky beam-lead diodes and a balanced circuit configuration to offer superior RF performance. The up-converter supports the full waveguide band operation for both LO and RF frequencies from 60 to 90 GHz with an extremely broad IF output from DC to 30 GHz. The up-converter offers a conversion loss of 9 dB typical and a high RF to LO port isolation of 30 dB.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum RF Frequency60 GHz
Maximum RF Frequency90 GHz
Minimum LO Frequency60 GHz
Maximum LO Frequency90 GHz
Minimum IF FrequencyDC
Maximum IF Frequency30 GHz
LO Pumping Power+13 dBm
Conversion Loss9 dB
RF PortWR-12 Waveguide
