E-Band Low Noise Amplifier, Wellprice

This is a Wellprice model that has been discounted for small cosmetic blemishes that do not affect longevity or performance. Customers who cannot accept any blemishes should consider the full-priced model SBL-6039034050-1212-E1 as an alternative solution. Read more about Wellprice Products here.

SBL-6039034050-1212-E1-WPC is a low noise amplifier with a typical small signal gain of 40 dB and a nominal noise figure of 5 dB across the frequency range of 60 to 90 GHz. The DC power requirement for the amplifier is +8 VDC/150 mA. The mechanical configuration offers an in line structure with WR-12 waveguides and UG-387/U anti-cocking flanges. Other port configurations, such as with 1 mm connectors or a right angle structure with WR-12 waveguides, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
