2 Way Right Angle Power Divider

60 to 90 GHz, 20 dB Port Isolation, WR-12 Waveguide, E- Band
SKU:SWP-60390302-12-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SWP-60390302-12-S1 is an E band, 2-way power divider with a typical insertion loss of 0.5 dB across the frequency range of 60 to 90 GHz. The divider offers 20 dB isolation and well-balanced ports, which can be used for in-phase power dividing or combining. This power divider comes as a right-angle configuration with WR-12 waveguides and UG-387/U anti-cocking flanges at the input and all outputs.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 9 $850.00
10 - 24 $765.00
25 - 49 $688.50

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency60 GHz
Maximum Frequency90 GHz
Insertion Loss0.5 dB
Port Isolation20 dB
Power Unbalance±0.3 dB
Input/Output Return Loss20 dB
Power Division2 Way
ConfigurationRight Angle (90°)
Input/Output PortsWR-12 WG
