E-Band Fixed Termination Load

60 to 90 GHz, 0.5 W Power Handling, WR-12 Waveguide
Availability:1 to 2 Weeks ARO
SWL-1227-S1 is a low power, E-Band termination load that covers the frequency range of 60 to 90 GHz. The termination load exhibits a typical return loss of 32 dB. It is designed and manufactured to offer a good match for system applications. Custom levels of power handling are available under different model numbers.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency60 GHz
Maximum Frequency90 GHz
Power Handling, Watts0.5 W
Power Handling, dBm27 dBm
Return Loss32 dB
Load TypeFixed
Waveguide PortWR-12 Waveguide
