V-Band Dual Channel, Doppler Sensor Module

60.0 GHz, +24 dBm Transmitting Power
SKU:SSM-60324-D1
SSM-60324-D1 is a V band Doppler sensor module that is designed and manufactured for medium range measurements of a moving target's speed and travel direction. The sensor module has an operating frequency of 60.0 GHz and takes a nominal bias of +8.0 VDC/1,750 mA. The sensor module is configured with a mechanically tuned oscillator, an isolator, a directional coupler, a circulator, a balanced I/Q mixer, and an oscillator voltage regulator. The directional coupler is used to sample the LO power to pump the mixer, and the circulator is used as a TX/RX diplexer. Various antennas can be integrated with the module to form sensor heads for many system applications.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 $14,365.00
2 $13,646.75
3 - 4 $12,964.41

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

RF Center Frequency60.0 GHz
Transmitting Power+24 dBm
Minimum IF FrequencyDC
Maximum IF Frequency3 GHz
Frequency Stability-6.0 MHz/°C
Power Stability-0.04 dB/°C
DC Bias+8.0 VDC/1,750 mA
ChannelDual
