WR-28 Waveguide Probe Antenna

6.5 dBi Gain, Ka-Band
SKU:SAP-28-R2
Availability:IN STOCKPlease contact us if you need more units than what is available online.
Select up to 4 products to compare.
Select up to 4 products to compare.
This model may be purchased with optional antenna testing services.
A gain measurement test is offered under service number FTA-0400GAIN-AA.
A 2D pattern measurement test is offered under service number FTA-0400PATT-AA.

CLICK HERE to read more about our antenna measurement capabilities.

SAP-28-R2 is a WR-28 waveguide Ka-band probe antenna that operates from 26.5 GHz to 40 GHz. The Ka-band probe antenna offers 6.5 dBi nominal gain and 115 degrees typical half power beamwidth on the E-Plane and 60 degrees typical half power beamwidth on the H-Plane. The antenna supports linear polarized waveforms. The input of this antenna is a WR-28 waveguide with UG599/U flange.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency26.5 GHz
Maximum Frequency40 GHz
Gain6.5 dBi
3 dB Beamwidth, E-Plane115°
3 dB Beamwidth, H-Plane60°
Return Loss12 dB
PolarizationLinear
Antenna PortWR-28 Waveguide
