This item is oversized and will require special packaging. Pricing for a custom crate will be quoted separately.

STY-MAA-AP-222F-R1 is a Q-band open ended waveguide probe assembly that operates from 33 GHz to 50 GHz. The antenna offers 6.5 dBi nominal directivity, a typical half power beamwidth of 115 degrees on the E-plane and 60 degrees on the H-plane. The antenna supports linear polarized waveforms. The RF port is a right angle (90°) 2.4 mm coax connector. The antenna is mounted on a universal mounting cage, which is constructed from sturdy black anodized aluminum plates and optical grade stainless steel posts. The cage includes an integrated bubble level and a removable Velcro fastened absorber shield. The open ended waveguide probe assembly is offered for near-field antenna range gain and pattern measurement purposes, but it can be also used for general purpose system set ups.
