V-Band Orthomode Transducer, Limited Run

This is a Limited Run model, so inventory may not be restocked. Customers who anticipate long-term requirements should consider SAT-603-14115-C1 as an alternative solution. Read more about Limited Run Products here.

SAT-613-14115-C1 is a WR-15 orthomode transducer (OMT) operating between 59 and 62 GHz. It separates a circular or elliptical polarized waveform into two linear, orthogonal waveforms or combines two linear polarized waveforms into one circular or elliptical polarized waveform or vice versa. The OMT also supports either vertical or horizontal polarized waveguide forms with more than 30 dB cross polarization rejections. The OMT shows high port isolation while providing a low insertion loss. The OMT is configured with a 0.141” diameter circular waveguide for the antenna port and two WR-15 waveguides for the horizontal and vertical ports. All ports have standard UG-385/U anti-cocking flanges and 4-40 threaded holes.
