WR-15 Waveguide Bandpass Filter

SWF-61304350-15-B1 is a V band waveguide bandpass filter with a passband frequency of 58.6 to 63.4 GHz and rejection frequencies from DC to 56.0 GHz and 68.0 to 80.0 GHz. The nominal insertion loss of the bandpass filter is 2.0 dB and the typical rejection is 50 dB. Since both low end and high end cut off frequencies can be selected by modifying the design, custom designs are available under different model numbers.
