X6 Active Frequency Multiplier

55 to 72 GHz, +26 dBm Output Power, WR-15 Waveguide, V-Band
SKU:SFA-553723626-15SF-E1
SFA-553723626-15SF-E1 is a V-Band active X6 frequency multiplier. The multiplier has an input frequency of 9.16 to 12 GHz with a typical input power of +3 dBm and an output frequency of 55 to 72 GHz with a typical output power of +26 dBm. The multiplier also has a typical harmonic suppression of -15 dBc. The DC power requirement for the multiplier is +8 VDC/1.6 A. The input port configuration is an SMA (F) connector and the output is a WR-15 waveguide with a UG-385/U anti-cocking flange. Other port configurations are available under different models.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: 3A001.b.7
Login to view pricing

Bulk Pricing

Quantity Price
1 $7,075.00
2 $6,721.25
3 - 4 $6,385.19

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Output Frequency55 GHz
Maximum Output Frequency72 GHz
Output Power+26 dBm
Minimum Input Frequency9.16 GHz
Maximum Input Frequency12 GHz
Input Power+3 dBm
DC Bias+8 VDC/1.6 A
Output PortWR-15 WG
Input PortSMA (F)
