14th Harmonic Mixer

50 to 75 GHz RF, 3 to 6.1 GHz LO, DC to 1.3 GHz IF, WR-15 Waveguide, V-Band
SKU:SFH-15SFSF-A3
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SFH-15SFSF-A3 is a V-Band balanced harmonic mixer that is specially designed for use with Keysight’s spectrum analyzer series. The mixer employs high performance, GaAs Schottky flip chip diodes and a balanced configuration to produce superior RF performance. With an IF range of DC to 1.3 GHz, the harmonic mixer uses the harmonic number 14 of a 3.0 to 6.1 GHz LO at +16 dBm to translate 50 to 75 GHz. The harmonic mixer has a conversion loss of 40 dB.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 2 $3,000.00
3 - 4 $2,850.00
5 - 9 $2,707.50

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to View Pricing

Technical Details

Minimum RF Frequency50 GHz
Maximum RF Frequency75 GHz
Minimum LO Frequency3.0 GHz
Maximum LO Frequency6.1 GHz
Minimum IF FrequencyDC
Maximum IF Frequency1.3 GHz
Conv. Loss40 dB
Harmonic Number14
RF PortWR-15 Waveguide
