3-Port Directional Coupler, Limited Run

50 to 75 GHz, 6 dB Coupling, 40 dB Directivity, WR-15 Waveguide, V-Band
Availability:IN STOCKPlease contact us if you need more units than what is available online.
This is a Limited Run model, so inventory may not be restocked. Customers who anticipate long-term requirements should consider SWD-0640H-15-SB as an alternative solution. Read more about Limited Run Products here.

SWD-0640H-15-SB-MT is a V-band, three-port waveguide directional coupler that delivers a 6 dB nominal coupling level and 30 dB minimum directivity across the full waveguide band from 50 to 75 GHz. The three-port coupler uses a traditional multi-hole and split block design to achieve a flat coupling level, high directivity, and low insertion loss. The RF ports of the coupler are WR-15 waveguides with UG-385/U flanges. Other standard coupling levels (3, 6, 10, 20, 30, and 40 dB) are available under different model numbers as SWD-XX40H-15-SB-MT, where XX is the desired coupling level.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency50 GHz
Maximum Frequency75 GHz
Insertion Loss1.0 dB
Coupling6 dB
Directivity40 dB
Coupler Type3-Port Multi-hole, Split-block
RF PortsWR-15 WG
