V-Band Low Noise Amplifier, Extended Temperature

50 to 75 GHz, 35 dB Gain, 5.0 dB Noise Figure, In-line WR-15 Waveguide
SKU:SBL-5037533550-1515-E1-ET
SBL-5037533550-1515-E1-ET is a low noise amplifier with a typical small signal gain of 35 dB and a nominal noise figure of 5 dB across the frequency range of 50 to 75 GHz. The DC power requirement for the amplifier is +8 VDC/150 mA. The mechanical configuration offers an in line structure with WR-15 waveguides and UG-385/U anti-cocking flanges. Other port configurations, such as with 1 mm connectors or a right angle structure with WR-15 waveguides, are also available under different model numbers. This model is tested to operate in the extended temperature range of -40° C to +85° C.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency50 GHz
Maximum Frequency75 GHz
Gain35 dB
Noise Figure5.0 dB
P1dB+11 dBm
Input Return Loss8 dB
Output Return Loss8 dB
DC Bias+8 VDC/150 mA
RF Input/OutputWR-15 Waveguide
