V-Band Compact Faraday Isolator

50 to 75 GHz, 28 dB Isolation, 1.5 dB Insertion Loss, WR-15 Waveguide, 90° Twist
Availability:IN STOCKPlease contact us if you need more units than what is available online.
STF-15-91-C is a full band Faraday isolator that operates from 50 to 75 GHz. The Faraday isolator is constructed with a longitudinal, magnetized ferrite rod that causes a Faraday rotation of the incoming RF signal. The compact, robust package is ideal for system integration and testing applications and features a 90° twist between the input port and output port. The Faraday isolator offers 28 dB typical isolation and 1.5 dB nominal insertion loss with good flatness. The input and output ports are WR-15 waveguides with UG-385/U flanges. An in-line configuration is available under model number STF-15-S1-C.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency50 GHz
Maximum Frequency75 GHz
Insertion Loss1.5 dB
Isolation28 dB
Return Loss14 dB
Power Handling1.5 W
RF PortWR-15 Waveguide
