V-Band Double Sideband Modulator

50 to 75 GHz, +10 dBm Input P1dB
SKU:SFF-50375313-1515KF-N1-M
Availability:1 Week ARO
SFF-50375313-1515KF-N1-M is a V Band balanced double sideband (DSB) modulator that utilizes a high-performance GaAs pHEMT-based MMIC chip to offer superior RF performance. The modulator supports the full waveguide band operation from 50 to 75 GHz. The modulator also supports an extremely broad bandwidth of IF from DC to 25 GHz. The mixer offers a typical conversion loss of 13 dB across the full waveguide bandwidth and a high input P1dB of +10 dBm when the IF port is pumped at ± 2.5 VP-P modulation level. The modulator is ideal candidate for high input P-1dB applications.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 2$3,200.00
3 - 4$3,040.00
5 - 9$2,888.00

Bulk Pricing

Login to View Pricing

Technical Details

Output RF Frequency Minimum50 GHz
Output RF Frequency Maximum75 GHz
IF Frequency MinimumDC
IF Frequency Maximum25 GHz
Input P1dB+10 dBm
Conversion Loss13 dB
RF In to RF Out Rejection30 dB
