V-Band Fixed Termination Load

50 to 75 GHz, 0.5 W Power Handling, WR-15 Waveguide
SKU:SWL-1527-S1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SWL-1527-S1 is a low power, V-Band termination load that covers the frequency range of 50 to 75 GHz. The termination load exhibits a typical VSWR of 1.05:1. It is designed and manufactured to offer a good match for system applications. Custom levels of power handling are available under different model numbers.
ECCN: EAR99
To view pricing or check order status

Bulk Pricing

QuantityPrice
1 - 24$490.00
25 - 49$441.00
50 +$396.90

Bulk Pricing

Sign In / Create An Account to view pricing

Technical Details

Minimum Frequency50 GHz
Maximum Frequency75 GHz
Power Handling, Watts0.5 W
Power Handling, dBm27 dBm
VSWR1.05
Load TypeFixed
Waveguide PortWR-15 Waveguide
