V-Band Low Noise Amplifier

50 to 70 GHz, 35 dB Gain, 5.0 dB Noise Figure, 1.85 mm (F)
Availability:4 to 6 Weeks ARO
SBL-5037033550-VFVF-S1 is a low noise amplifier with a typical small signal gain of 35 dB and a nominal noise figure of 5 dB across the frequency range of 50 to 70 GHz. The DC power requirement for the amplifier is +8 VDC/150 mA. The RF connectors are female V connectors. Other port configurations, such as male V connectors and WR-15 waveguides for either the input or output port, are also available under different model numbers.
Login to View Pricing

Bulk Pricing

1 - 2$2,950.00
3 - 4$2,802.50
5 - 9$2,662.38

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency50 GHz
Maximum Frequency70 GHz
Gain35 dB
Noise Figure5.0 dB
P1dB+11 dBm
Input Return Loss8 dB
Output Return Loss8 dB
DC Bias+8 VDC/150 mA
RF Input/Output1.85 mm (F)
