8-Way In-line Power Divider

50 to 66 GHz, 20 dB Adjacent Port Isolation, WR-15 Waveguide, V-Band
SKU:SWP-50366308-15-E1
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SWP-50366308-15-E1 is a V band, 8-way in-line waveguide power divider that operates across the frequency range of 50 to 66 GHz. The power divider offers a typical insertion loss of 1.7 dB at each output port and a typical isolation of 20 dB. The ports are well balanced and in phase for either power dividing or power combining applications across the full band. This model offers an end launch design with WR-15 waveguides and UG-385/U flanges. Other configurations are available under different model numbers.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $2,350.00
5 - 9 $2,115.00
10 - 24 $1,903.50

Bulk Availability

QuantityAvailability

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency50 GHz
Maximum Frequency66 GHz
Insertion Loss1.7 dB
Port Isolation20 dB
Amplitude Imbalance±0.4 dB
Port VSWR1.2
Power Division4 Way
ConfigurationIn-line (180°)
Input/Output PortsWR-15 WG
