U-Band Varactor Tuned Gunn Oscillator

50 GHz, ±0.5 GHz Varactor Tuning Bandwidth, +10 dBm Output Power, WR-19 Waveguide
SKU:SOV-50305215-19-G1
Availability:Contact Us for Quote
Select up to 4 products to compare.
Select up to 4 products to compare.
SOV-50305215-19-G1 is a U-Band, Varactor tuned Gunn oscillator that utilizes a high-performance GaAs Gunn diode and proprietary cavity design to deliver +15 dBm typical power. The oscillator features a Varactor tuning range of ±500 MHz and delivers low AM/FM noise and harmonic emissions. Compared to its counterparts, such as multiplier based sources, the Gunn oscillator is a lower cost and cleaner source. The performance of the oscillator can be further enhanced by adding an isolator, Gunn oscillator modulator/regulator and temperature heater.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Center Frequency50 GHz
Output Power+10 dBm
Mechanical Tuning Range
Varactor Tuning Range±500 MHz
Bias+4.0 VDC/800 mA
Varactor Tuning Voltage Range0 to +25 VDC
RF PortWR-19 Waveguide
Varactor Tuning PortSMA (F)
