4-Way Coaxial Power Splitter

5 to 40 GHz, 2.92 mm (F)
SKU:SCS-0534032015-KFKF-42
Availability:4 to 6 Weeks ARO
SCS-0534032015-KFKF-42 is a coaxial 4-way power splitter with a typical insertion loss of 2 dB at each output port and a typical isolation of 15 dB across the frequency range of 5 to 40 GHz. The power splitter has a nominal power handling of 20 W (CW) and a typical amplitude unbalance of ±0.7 dB. The return loss for all ports is 10 dB typical. The RF connectors of the power splitter are female 2.92 mm (K) connectors.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 4$1,250.00
5 - 9$1,125.00
10 - 24$1,012.50

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency5 GHz
Maximum Frequency40 GHz
Ways4
Insertion Loss2.0 dB
Port Isolation15 dB
Return Loss10 dB
Impedance50 Ohms
RF ConnectorsK (F)
