WR-15 Coaxial Highpass Filter

43 to 75 GHz, 40 dB Rejection from DC to 35 GHz
SKU:SCF-43335340-15VFVF-H1
Availability:1 Week ARO
SCF-43335340-15VFVF-H1 is a coaxial highpass filter with a passband frequency from 43 to 75 GHz. The filter rejects the frequencies from DC to 35 GHz and provides a nominal insertion loss of 1.0 dB in its passband with low ripple. Typical rejection for this model is 40 dB. The RF ports offer female 1.85 mm (V) connectors. However, the models with other connector type, such as male connector, are also available under different model numbers.
ECCN: EAR99
Login to View Pricing

Bulk Pricing

QuantityPrice
1 - 2$3,400.00
3 - 4$3,230.00
5 - 9$3,068.50

Bulk Pricing

Login to View Pricing

Technical Details

Minimum Passband Frequency43 GHz
Maximum Passband Frequency75 GHz
Minimum Rejection FrequencyDC
Maximum Rejection Frequency35 GHz
Rejection40 dB
Insertion Loss1.0 dB
Return Loss10 dB
Impedance50 Ohms
Power Handling10 W
RF Ports1.85 mm (F)
