WR-19 Waveguide Bandpass Filter

42 to 54 GHz Passband, 40 dB Rejection from DC to 38 GHz and 57 to 90 GHz, U-Band
Availability:IN STOCKPlease contact us if you need more units than what is available online.
SWF-48312340-19-B1 is a U band waveguide bandpass filter with a passband frequency of 42 to 54 GHz and rejection frequencies from DC to 38 GHz and 57 to 90 GHz. The nominal insertion loss of the bandpass filter is 1.5 dB and the typical rejection is 40 dB. Since passband frequency can be selected by modifying the design, custom designs are available under different model numbers.
Login to view pricing

Bulk Pricing

Quantity Price
1 - 4 $2,050.00
5 - 9 $1,845.00
10 - 24 $1,660.50

Bulk Availability

1 - 5In Stock

Bulk Pricing

Login to view pricing

Technical Details

Minimum Passband Frequency42 GHz
Maximum Passband Frequency54 GHz
Minimum Rejection Frequency, Low SideDC
Maximum Rejection Frequency, Low Side38 GHz
Minimum Rejection Frequency, High Side57 GHz
Maximum Rejection Frequency, High Side90 GHz
Rejection40 dB
Waveguide PortWR-19 Waveguide
