U-Band Balanced Upconverter

40 to 60 GHz, DC to 20 GHz IF, +13 dBm LO Power, WR-19 Waveguide
SKU:SFU-19-N1
Availability:3 to 5 Days ARO
SFU-19-N1 is a U-Band balanced upconverter that utilizes high performance GaAs Schottky beam-lead diodes and a balanced circuit configuration to offer superior RF performance. The upconverter supports the full waveguide band operation for both LO and RF frequencies from 40 to 60 GHz with an extremely broad IF output from DC to 20 GHz. The upconverter offers a conversion loss of 8 dB typical and a high RF to LO port isolation of 30 dB.
ECCN: EAR99
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum RF Frequency40 GHz
Maximum RF Frequency60 GHz
Minimum LO Frequency40 GHz
Maximum LO Frequency60 GHz
Minimum IF FrequencyDC
Maximum IF Frequency20 GHz
LO Pumping Power+13 dBm
Conversion Loss8 dB
RF PortWR-19 Waveguide
