U-Band Power Amplifier with Uni-Guide™

40 to 60 GHz, 35 dB Gain, +19 dBm P1dB, 1.85 mm (F), WR-19 Waveguide
SKU:SBP-4036033519-VF19-E1
Availability:1 to 2 Weeks ARO
Select up to 4 products to compare.
Select up to 4 products to compare.
SBP-4036033519-VF19-E1 is a U band power amplifier with a typical small signal gain of 35 dB and a nominal P1dB of +19 dBm in the frequency range of 40 to 60 GHz. The DC power requirement for the amplifier is +8 VDC/650 mA. The input configuration is a female 1.85 mm connector and the output port is a WR-19 Uni-Guide™ waveguide with a UG-383/U-M anti-cocking flange. Other port configurations are available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
ECCN: EAR99
    Login to view pricing

    Bulk Pricing

    Login to view pricing

    Technical Details

    Minimum Frequency40 GHz
    Maximum Frequency60 GHz
    Gain35 dB
    P1dB+19 dBm
    Psat+20 dBm
    Input Return Loss10 dB
    Output Return Loss10 dB
    DC Voltage+8 VDC
    DC Bias650 mA
    RF Input/Output1.85 mm (F)/WR-19 Uni-Guide™ Waveguide
    ConfigurationStandard
