U-Band Power Amplifier

40 to 60 GHz, 34 dB Gain, +36 dBm Psat, WR-19 Waveguide
SKU:SBP-4036033436-1919-EP
Availability:Contact Us for Quote
SBP-4036033636-1919-EP is a power amplifier with a typical small signal gain of 34 dB and a nominal Psat of +36 dBm across the frequency range of 40 to 60 GHz. The DC power requirement for the amplifier is +20 VDC/3.6 A. The mechanical configurations is an inline structure with WR-19 waveguide with UG-383/U-M Anti-Cocking Flange as its input port and output port.
ECCN: 3A001.b.4
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency40 GHz
Maximum Frequency60 GHz
Gain34 dB
Psat+36 dBm
Pin+12 dBm
Input Return Loss7 dB
Output Return Loss5 dB
DC Voltage+20 VDC
DC Bias3.6 A
RF Input/OutputWR-19 Waveguide
