U-Band Fixed Attenuator

40 to 60 GHz, 3 dB, 10 Watt Power Handling, WR-19 Waveguide
STA-03-19-FS-40 is a 10 watt fixed attenuator that is used in millimeterwave systems and operates from 40 to 60 GHz. The attenuator has a nominal fixed attenuation value of 3 dB across the entire U band. The attenuator is uniquely designed and fabricated for full waveguide band applications and displays an extremely flat frequency response across the full bandwidth. Various attenuation values are available under different model numbers.
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Minimum Frequency40 GHz
Maximum Frequency60 GHz
Attenuation3 dB @ 50 GHz
Return Loss14 dB
Power Handling10 W
RF PortWR-19 Waveguide
Attenuator TypeFixed
