U-Band Low Noise Amplifier with Uni-Guide™

37 to 51.5 GHz, 24 dB Gain, 4.5 dB Noise Figure, In-line WR-19 Waveguide
Availability:4 to 6 Weeks ARO
SBL-3735232445-1919-E1 is a low noise amplifier with a typical small signal gain of 24 dB and a nominal noise figure of 4.5 dB across the frequency range of 37 to 51.5 GHz. The DC power requirement for the amplifier is +6 VDC/130 mA. The mechanical configuration offers a in-line structure with WR-19 Uni-Guide™ waveguides. Other port configurations, such as a right angle structure with WR-19 waveguides or 1.85 mm connectors, are also available under different model numbers.

Your application may require a heatsink. Visit our Heatsink Blog for assistance with choosing an appropriate heatsink for use with this model.
Login to View Pricing

Bulk Pricing

Quantity Price
1 - 2 $2,950.00
3 - 4 $2,802.50
5 - 9 $2,662.38

Bulk Availability


Bulk Pricing

Login to View Pricing

Technical Details

Minimum Frequency37 GHz
Maximum Frequency51.5 GHz
Gain24 dB
Noise Figure4.5 dB
P1dB+12 dBm
Input Return Loss8 dB
Output Return Loss8 dB
DC Bias+6 VDC/130 mA
RF Input/OutputWR-19 Uni-Guide™ Waveguide
