Level Setting Radar Target Simulator

WR-28, DC to 13.5 GHz I/Q Frequency, 25 dB Carrier Rejection, 20 dB Image Rejection
STR-353-28-L1 is a radar doppler simulator that operates from 26.5 to 40 GHz with a WR-28 waveguide input/output. The simulator utilizes a single-sideband-modulator to modulate the incoming signal transmitted by the radar under test and sends back either a higher or lower band signal through a diplexer. The frequency-shifted signal is transmitted back to the radar under test as a Doppler signal. Target characteristics can be adjusted by changing the I and Q channel frequency and phase. The routing attenuation is adjusted by the level setting attenuator which can be calibrated to simulate the radar cross section (RCS).
Login to view pricing

Bulk Pricing

Login to view pricing

Technical Details

Frequency26.5 to 40 GHz
Carrier Rejection25 dB
Image Rejection20 dB
I/Q Frequency MinimumDC
I/Q Frequency Maximum13.5 GHz
RF PortWR-28 Waveguide
I/Q PortsSMA (F)
